Protective cap US 3 support, black

morepic-1

morepic-2

Protective cap US 3 support, black

Item no. 6338456 | EAN 4012196594429

Product description

Product description

Protective cap to cover the ends of US 3 supports. Graphite black (RAL 9011).

Technical data

Technical data

Colour	Graphite black; RAL 9011
Dimension	25x50
Height	25 mm
Length	55 mm

Material	Polyethylene
Suitable for profile shapes	U profile
Version for	End cap
Width	35,5 mm

All types

All types

Types		Item no.	Quantity	SSU
US 3 KS OR		6338458	piece	20 piece
US 3 KS SW		6338456	piece	20 piece

Downloads

Data sheet US 3 KS SW / 6338456 , 0.14MB , pdf

Guide KTS cable tray systems , 1.61MB , pdf

Catalogue Cable support systems , 45.23MB , pdf

Mounting instructions General information on the mounting , 2.61MB , pdf

Mounting instructions Mounting instructions, U support systems , 1.76MB , pdf

Product graphic US 3 KS SW / 6338456, 45.90 kB, jpg

Scale drawing US 3 KS SW / 6338456, 10.35 kB, jpg

US 3 KS SW / 6338456

6338456_KSTP1.stp, 54.23 kB
